Shelly Wall switch 4 + Shelly Plus i4
Available
Wi-Fi operated 4 digital inputs controller + Shelly Wall Switch 4
Shelly Plus i4 allows you to manually activate or deactivate any created scene, run synchronized actions, or execute complex trigger scenarios. Shelly Plus i4 is an input reader device (it does not contain relays).
+ with Shelly Wall Switch 4-button
specifications
| POWER | |
|---|---|
| Power supply AC | 110-240V ±10%, 50/60Hz |
| Power supply DC | No |
| Channels | 4 Channel Input |
| SPECIAL FUNCTIONS | |
| Device temperature protection | Yes |
| Overload protection | No |
| Multi-click support | Up to 12 possible actions |
| FEATURES | |
| HTTP/HTTPS webhooks | Yes |
| Custom scripts (mJs) | Yes |
| Operational temperature | -20°C to + 40 °C |
| Device power consumption | < 1 W |
| Intelligent On/Off | Yes |
| Local and remote control | Yes |
| Sunrise/Sunset | Yes |
| Weekly Schedule | Yes |
| CONNECTIVITY | |
| Wireless | Yes |
| Wi-Fi Protocol | 802.11 b/g/n |
| Wi-Fi Radio frequency | 2412-2472 МHz |
| Wi-Fi Radio signal power | 1mW |
| Wi-Fi Range | up to 50 m outdoors and up to 30 m indoors (depending on the building materials) |
| DIMENSIONS | |
| Size | 42 x 38 x 17mm |
